Overview

The Grade with 2D system displays real-time bucket location relative to grade on the highresolution touchscreen color monitor with indicate-only and laser capability. Select your desired target depth and target slope and the system will give you real-time guidance on depth, slope, and horizontal distance to grade, with height and depth alerts that indicate target grade or obstacles.

Benefits & Features

• The standard Grade with 2D system displays real-time bucket location relative to grade on the high-resolution touchscreen color monitor with indicate-only and laser capability.
• Select your desired target depth and target slope and the system will give you real-time guidance on depth, slope, and horizontal distance to grade, with height and depth alerts that indicate target grade or obstacles.
• Easily adjust target depth and slope with joystick commands, the touchscreen interface, or the jog dial.
• The excavator and Grade with 2D work as a system while on-board processors and fast response sensors deliver precise real-time bucket tip elevation guidance.
• Start digging and simply check grade from inside the cab.
• The optional laser catcher with laser transmitter compatibility allows the excavator to move—bench once,reference the laser, and continue digging to grade across the jobsite.
• Use the Grade with 2D system to increase your efficiency and productivity when digging and grading basements, footings, foundations, utility trenches, slopes, and drainage ditches.
• Works with standard Grade Assist that adds semiautonomous digging capability and activates single lever digging.

• Minimize costs by reaching target grade quickly and save costs associated with time, labor, fuel, and material consumption.
• Integrated components that are protected from damage ensure long life, reliable control, and cost-saving results.
• Work confidently without guesswork while cutting and filling to exact specifications without overcutting and having to refill a cut.
• Height and depth alerts from inside the cab indicate obstacles that could damage your excavator and cost you money.
• Work safer with fewer ground personnel checking grade in the trench or around your excavator.

• Grade with Advanced 2D adds in-field design capability with an additional high-resolution 10 in (254 mm) touchscreen monitor.
• Grade with 3D works for complex cuts and fills requiring pinpoint precession as the system provides real-time position guidance and your excavator’s exact position relative to GPS and GLONASS systems.
• All upgrades can be installed at the factory or any time after purchase.
